29 November 2014
Marking a first in space, Sentinel-1A and Alphasat have linked up by laser stretching almost 36 000 km across space to deliver images of Earth just moments after they were captured.
This important step demonstrates the potential of Europe’s new space data highway to relay large volumes of data very quickly so that information from Earth-observing missions can be even more readily available.
Having timely access to imagery from the Sentinel-1 mission, for example, is essential for numerous applications such as maritime safety and helping to respond to natural disasters.
Linking to EDRS for continual data delivery
Orbiting from pole to pole about 700 km up, Sentinel-1A transmits data to Earth routinely, but only when it passes over its ground stations in Europe. However, geostationary satellites, hovering 36 000 km above Earth, have their ground stations in permanent view so they can stream data to Earth all the time.
This takes a great deal of coordination between the different teams working intensively. Later on, in routine operations, this will be fully automated.
Creating a link between the two kinds of satellites means that more information can be streamed to Earth, and almost continuously. Engineers have turned to laser to accomplish this.
Berlin from Sentinel-1A via laser
Funded by ESA and the DLR German Aerospace Center, Tesat has developed a laser communications terminal and downlink system that is carried on the geostationary Alphasat, Europe’s largest telecommunications satellite. This novel unit’s counterpart is flying on Sentinel-1A.
Over the past few weeks the Sentinel-1A operations teams at ESA’s European Space Operations Centre, ESOC, in Darmstadt, Germany, and ESA’s Earth Observation Centre, ESRIN, in Frascati, Italy, and German Space Operations Center, GSOC, in Oberpfaffenhofen, Germany, have been working intensively to prepare for the first laser link tests.
The image on the right, showing Berlin in Germany, is one of the first images delivered using this state-of-the-art technology.
“Demonstrating laser data link-ups in space has involved excellent teamwork by many at ESA, Inmarsat, Tesat and DLR,” says ESA’s Head of Mission Operations, Paolo Ferri.
“I am especially proud of the major contribution the operations teams at ESOC and ESRIN have provided to the success of this activity, which will significantly improve data availability from Earth observation missions and enhance benefits for all citizens in the future.”
Heads of various agencies gathered at ESOC today to follow the operators as they linked the two satellites by laser. Radar data over Asia were acquired and downlink to Earth in near-real time.
Magali Vaissiere, ESA’s Director of Telecommunications and Integrated Applications, said, “Today, space systems have become part of the global Big Data challenge.
“You can visualise the link of today as an optical fibre in the sky that can connect the Sentinels back home to Europe, from wherever they are on their orbit around Earth.
The gold standard for EDRS
“The link is operated at 1.8 Gbit/s, with a design that could scale up to 7.2 Gbit/s in the future. Never has so much data travelled in space.”
Following processing by ESA’s Copernicus Ground Segment, images will be online and available to the public through the Sentinel data website: https://sentinel.esa.int/web/sentinel/home
Philippe Goudy, Head of ESA’s Earth Observation Projects Department, said, “This laser link between the two satellites marks an important milestone in efforts to further ensure that the Copernicus environmental services are fed with large volumes of data that are not only accurate, but are also provided as quickly as possible.
“By improving the availability of Copernicus information and services, EDRS will help to unleash the economic potential of Copernicus and thus give a boost to the overall economy.”
As today’s events show, this precursor to the future European Data Relay System (EDRS) has paved the way for an entirely new approach of delivering data.
Gerd Gruppe, DLR Member of the Executive Board Space Administration, added, “This technology has been fostered by DLR for more than 20 years. Today, laser communication technology allows a transmission of 2.7 million full written pages per minute. That’s why we have to establish this technology as a standard of communication.
“Space laser communication is the future!”
The first EDRS element will be carried on the Eutelsat-9B satellite, launched next year. In the meantime, Sentinel-1A will now be able to connect through the precursor laser terminal on Alphasat. Sentinel-2A, scheduled for launch next spring, also carries the same payload.
Both Sentinel missions are dedicated to delivering key information for Europe’s environmental monitoring Copernicus programme.
